Huawei CloudEngine S5732-H Series All-Optical Switch S5732-H24S6Q

Product Description


CloudEngine S5732-H series switches are the next generation of enhanced all-optical GE/10 GE hybrid switches with 24 or 48 downlink ports and six fixed 40 GE uplink ports, supporting system switching capacity of up to 2.4 Tbit/s.

CloudEngine S5732-H series switches offer support for native Access Controller (AC), management of up to 1024 Access Points (APs), with wired and wireless convergence. The series provides free mobility, ensuring a consistent user experience, with Virtual Extensible LAN (VXLAN) and network virtualization meeting the requirements of multi-purpose campus networks. A built-in security probe supports abnormal traffic detection, threat analysis of encrypted traffic, and network-wide threat deception. The CloudEngine S5732-H series is therefore an ideal choice to serve in the aggregation or access layer in large- and medium-sized campus networks, in the core layer of small-sized campus networks, or in the access layer of data centers.



Delivering Abundant Services More Agilely

This CloudEngine S5732-H provides the integrated WLAN AC(native AC) function that can manage 1,024 APs, reducing the costs of purchasing additional WLAN AC hardware and breaking the forwarding performance bottleneck of an external WLAN AC. With this switch series, customers can stay ahead in the high-speed wireless era.

With the unified user management function, the CloudEngine S5732-H authenticates both wired and wireless users, ensuring a consistent user experience no matter whether they are connected to the network through wired or wireless access devices. The unified user management function supports various authentication methods, including 802.1x, MAC address, and Portal authentication, and is capable of managing users based on user groups, domains, and time ranges. These functions visualize user and service management and boost the transformation from device-centric management to user experience- centric management.

The CloudEngine S5732-H provides excellent quality of service (QoS) capabilities and supports queue scheduling and congestion control algorithms. Additionally, it adopts innovative priority queuing and multi-level scheduling mechanisms to implement fine-grained scheduling of data flows, meeting service quality requirements of different user terminals and services.

Note: The CloudEngine S5732-H can manage 16 APs by default . You can purchase licenses for more AP management on demand.


Providing Fine Granular Network Management More Agilely

The CloudEngine S5732-H uses the Packet Conservation Algorithm for Internet (iPCA) technology that changes the traditional method of using simulated traffic for fault location. iPCA technology can monitor network quality for any service flow anywhere and anytime, without extra costs. It can detect temporary service interruptions in a very short time and can identify faulty ports accurately. This cutting-edge fault detection technology turns "extensive management" to "fine granular management."

The CloudEngine S5732-H supports Two-Way Active Measurement Protocol (TWAMP) to accurately check any IP link and obtain the entire network's IP performance. This protocol eliminates the need of using a dedicated probe or a proprietary   protocol.

The CloudEngine S5732-H supports SVF and functions as a parent switch. With this virtualization technology, a physical network with the "Small-sized core/aggregation switches + Access switches + APs" structure can be virtualized into a "super switch", greatly simplifying network management.

With the Easy Deploy function, the CloudEngine S5732-H manages access switches in a similar way an AC manages APs. In deployment, access switches and APs can go online  with zero-touch configuration. In the Easy Deploy solution, the Commander collects topology information about the connected clients and stores the clients' startup information based on the topology. Clients can be replaced with zero-touch configuration.  The  Commander  can deliver  configurations  and scripts  to clients in batches and query the delivery results. In addition, the Commander can collect and display information about power consumption on the entire network.


Comprehensive VPN Technologies

The CloudEngine S5732-H supports the MPLS function, and can be used as access devices of high-quality enterprise leased line.

The CloudEngine S5732-H allows users in different VPNs to connect to the same switch and isolates users through multi- instance routing. Users in multiple VPNs connect to a provider edge (PE) device through the same physical port on the switch, which reduces the cost on VPN network deployment.



Models and Appearances




CloudEngine S5732-H24S6Q

20 x GE SFP ports, 4 x 10GE SFP+ ports, 6 x 40GE QSFP+ ports

1+1 power backup

Forwarding performance: 450 Mpps

Switching capacity: 600 Gbps/2.4 Tbps



CloudEngine S5732-H48S6Q

44 x GE SFP ports, 4 x 10GE SFP+ ports, 6 x 40GE QSFP+ ports

1+1 power backup

Forwarding performance: 486 Mpps

Switching capacity: 648 Gbps/2.4 Tbps



Product ModelCloudEngine S5732-H24S6QCloudEngine S5732-H48S6Q
Forwarding Performance450 mpps486 mpps
Switching Capacity2600 Gbit/s/2.4 Tbit/s648 Gbit/s/2.4 Tbit/s
Fixed Ports20 x GE SFP ports, 4 x 10 GE SFP+ ports, 6 x 40 GE QSFP+ ports44 x GE SFP ports, 4 x 10 GE SFP+ ports, 6 x 40 GE QSFP+ ports
Wireless ServicesManagement of up to 1024 APs
AP access control, AP domain management, and AP configuration template management
Radio channel management, unified static configuration, and dynamic centralized management
WLAN basic services, QoS, security, and user management
CAPWAP, tag/terminal location, and spectrum analysis
iPCACollection of real-time statistics on the number of lost packets and packet loss ratio at network and device level
Super Virtual Fabric (SVF)Functions as the parent node to virtualize downstream switches and APs vertically as one device for simpler management
Supports a two-layer client architecture
Supports third-party devices between SVF parent and clients
VXLANVXLAN L2 and L3 gateways
Centralized and distributed gateways
Configured through the NETCONF protocol
SecurityEncrypted Communication Analytics (ECA)
Threat trap technology
Network-wide security collaboration
InteroperabilityVBST (compatible with PVST, PVST+, and RPVST)
LNP (similar to DTP)
VCMP (similar to VTP)
