Product Description
200kg high efficiency natural gas lpg gas boiler
Product Description
1.Boiler water volume is small, with quick start of cold furnace,which can realize temperature and pressure rise during a short period of time.
2.Built-in multi steam and water separation technology,quality steam .
3.With multiple chain protection for water level,steam pressure,overheating ,which is safe and reliable
4.Fully skid-mounted ,centralized steam supply, could realize single independent or multiple units centralized control, exempted of installtion and design
Technical Parameters
| Model | LSS0.05-0.7-Y.Q | LSS0.1-0.7-Y.Q | LSS0.125-0.7-Y.Q | LSS0.2-0.7-Y.Q | LSS0.25-0.7-Y.Q | LSS0.3-0.7-Y.Q | LSS0.5-0.7-Y.Q | ||
| Project | Unit | ||||||||
| Rated evaporation | Kg/h | 50 | 100 | 125 | 200 | 250 | 300 | 500 | |
Rated working pressure | MPa | 0.7 | |||||||
Staturated steam temperature | ℃ | 170 | |||||||
Fuel consumption | Light diesel oil | kg/h | 3.5 | 6.8 | 8.5 | 14 | 16 | 20 | 33 |
| Natural gas | Nm³/h | 7 | 8.75 | 15 | 19 | 22 | 36.5 | ||
| LPG | 1.5 | 3 | 3.8 | 6 | 7.5 | 9 | 14.5 | ||
| City gas | 8.5 | 18 | 22.5 | 34 | 43 | 52 | 88 | ||
| Water capacity | L | 29 | 49.3 | 49.6 | 49.5 | 49.6 | |||
| a Main steam valve diameter | DN | 15 | 25 | 32 | 50 | ||||
| b Safety valve diameter | 20 | 25 | 40 | ||||||
| c Inlet diamater | 15 | ||||||||
| d Blowoff Valve diameter | 20 | 25 | |||||||
| Chimney diameter | 80 | 125 | 125 | 150 | 250 | ||||
| Overall size | L | mm | 820 | 880 | 900 | 1400 | 1500 | 1800 | |
| W | 890 | 1100 | 1150 | 1000 | 1100 | 1200 | 1300 | ||
| H | 1600 | 1800 | 1900 | 2200 | 2350 | ||||
| φDiameter | 600 | 650 | |||||||
| Weight | kg | 180 | 220 | 240 | 850 | 1150 | 1200 | 1680 | |
Related Products
Company Profile
FAQ
Q: Are you a factory or a trading company?
A: We are a 20-year-old industrial boiler factory , specializing in gas oil diesel electric fired boilers.
A: We are a 20-year-old industrial boiler factory , specializing in gas oil diesel electric fired boilers.
Now we are one of leading industrial boiler manufacturers in China.
Q: What is the Warranty for the boilers?
A: Our steam boiler warranty is one year, During the warranty period, any parts damaged, you can get a new
Q: What is the Warranty for the boilers?
A: Our steam boiler warranty is one year, During the warranty period, any parts damaged, you can get a new
parts for free.
Q: How long should we wait for delivery?
A. Usually it will take about 35-45 days for pressured boilers, If you need to change the voltage or pressure, it
need more time.
Q: What about your payment term?
A: Usually it would be 30% deposit payment, 70% balance before delivery. We accept T/T, L/C and other
Q: How long should we wait for delivery?
A. Usually it will take about 35-45 days for pressured boilers, If you need to change the voltage or pressure, it
need more time.
Q: What about your payment term?
A: Usually it would be 30% deposit payment, 70% balance before delivery. We accept T/T, L/C and other
payment way.
