Products Description
Road Construction 90KN high filtration efficiency 16.5t motor grader 4215D 4.3m blade
Fuel Efficient Cummins Engine.Innovative five-column , Low Vibration, Noise, Dust +UV Resistant cab.Meritor wet axle with
"no-spin" differential lock as standard.Innovative traction frame swing adjustment mechanism.
"no-spin" differential lock as standard.Innovative traction frame swing adjustment mechanism.
COMPACT DIMENSIONSEXTENDING UNDERCARRIAGE
SAFETY FRAME
SIMPLE CONTROL
SEASY MAINTENANCE
VERSATILITY
EXTENDING UNDERCARRIAGE
SAFETY FRAME
SIMPLE CONTROL
SEASY MAINTENANCE
VERSATILITY
EXTENDING UNDERCARRIAGE
Product Paramenters
Item | Value |
Product Name | Motor Grader |
Model | 4215D |
Rated Power | 162 kW (190 hp) @ 2200 rpm |
Operating weight | 12300 kg |
Drawbar pull | 90 kN |
Model | Cummins 6LTAA9.3 |
Emission regulation | Tier 2 / Stage II |
Type | Power shift |
Speeds | 6f / 3r |
Maximum travel speed, forward | 40 km/h |
Maximum travel speed, reverse | 26.2 km/h |
Turning radius | 7200 mm |
Articulation angle | ±27º |
Maximum overall height | 3380 mm |
Width over tires | 2600 mm |
Blade width | 4270 mm |
Overall length | 9140 mm |
