Suitable For Slurry and Pulp Material Vacuum Rake Dryer
ZPG Vacuum Harrow Rake Dryer
Product Description
Technical Parameters
| Item | |||||||||
| working volume | L | 300 | 450 | 600 | 900 | 1200 | 1800 | 2400 | 3000 |
| power | kw | 4 | 5.5 | 5.5 | 7.5 | 7.5 | 11 | 15 | 18.5 |
| Design pressure of jacket | Mpa | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 |
| pressure in the cylinder | Mpa | 0.096 | 0.096 | 0.096 | 0.096 | 0.096 | 0.096 | 0.096 | 0.096 |
Main Features
(1) the material is even dry; avoid oxidation, overheating; can get very low moisture content of the product, Packaging can be done without crushing operation.
(2) the evaporation intensity is high, generally can evaporate 2-10kg (water) / m2 x h.
(3) no air intervention, condenser load is very small, can be easily recycled material solvent.
(4) the solvent vapor entrainment is filtered by the bag filter without environmental pollution.
(5) energy consumption: General evaporation 1kg water vapor 1.3-1.5kg.
(6) the discharge valve is pneumatic short diameter ball valve, discharge convenient, and no accumulation phenomenon.
(7) the hot medium can be used water vapor, heat transfer oil, hot water.
Product Categories
Company Information
Packaging
Certified
Shipping
FAQ
Q: Are you a manufacturer or a trader?
We're a manufacturer with more than years professional production experience.
Q: Can you accept OEM?
Yes, OEM is acceptable. Just pls provide us the drawing or sample, we will production totally according to your required.
Q: Can you provide us the design drawing?
Yeah, of course, we will provide you the drawing after you payment or prepaid.
Q: Can your factory produce products according to our drawings?
Yes, we can. Most products can be customized, including the Logo on products.
Q: What kind of your packaging ?
Neutral plywood or wooden box packaging or according to customer’s requirements.
Q: How long is your delivery time?
Normally 30days after payment, and we promise we will delivery as soon as we can.
